Curved Glass Corners

Part of our Glass Wall System

A sleek, soft look.

Take the edge off with a curved glass elevation that seamlessly integrates with the rest of the DIRTT Construction System. Get a signature curve with the look you want. Use our modular approach to building to get rapid installation and long-term adaptability. Whether you’re streamlining your look or making a statement, our curved glass will change the way you look at construction.

Pricing Information

Features

Round out your look with a smooth stick-built corner assembly.
Wall system includes aluminum frames and monolithic, full-height glass panels.
Curved glass is ³⁄₈” (10 mm) thick.
Components are precision manufactured to accommodate base building conditions.
Sleek, non-generational design serves your space today and into the future.

Modularity supports adaptive reuse and future flexibility.

Customization

Wall height configuration is fully customizable.
Extrusions available in our Classic Glass rectilinear and sleek Inspire™ profiles.
Curves available in a variety of signature radius measurements.
Get a framed or seamless look.
Header can attach directly to ceiling, soffit, bulkhead, or structure.
Choose from clear and low-iron varieties of tempered or laminated glass.
Limit transfer of smoke with our non-rated smoke partition.

Finish Options

Technical Overview

Wall thickness Inspire: 2” (51 mm)
Wall thickness Classic rectilinear: 4” (102 mm)
Curve Radius Inspire: 24” (610 mm), 36” (914 mm), or 48” (1.22 m)
Curve Radius Classic rectilinear: 36” (914 mm) or 48” (1.22 m)
Maximum Wall Height Inspire: 10’ (3.0 m)
Maximum Wall Height Classic rectilinear: 10’ (3.0 m)
Wall height adjustability Inspire: -½” (12 mm) +⅝” (15 mm)
Wall height adjustability Classic rectilinear: -⅜” (10 mm) +1 ⅛” (29 mm)
Standard header uses ceiling track, ceiling grid clips, or metal stud kickers
Standard base track secures to the base building with seismic anchoring
SCS Indoor Advantage Gold certified
